Specifications:
| | Bus system: | PCI (AGP in progress)
|
| 2D/3D accelerators: | PERMEDIA 2 from 3Dlabs.
|
| Display memory: | 4 MB (upgradable to 8 MB) and 8 MB SGRAM
|
| Pixel clock: | up to 230 MHz
|
| Feature connector: | VESA compatible
|
| Standards: | VESA Video BIOS, DPMS, DDC2B, Plug & Play
|
| Graphics standards: | Microsoft( DirectX (Direct3D,, DirectDraw, DirectVideo, DirectShow) and EnDIVE-Support,
OpenGL(r)
|
| 3D features: | texture mapping, bilinear and point filtering, alpha blending, fogging, Gouraud shading, triangle
setup
|
| Video connectors: | Video in/out via S-video/hosiden, video in via composite/cinch, video out via adapter cable to
composite/cinch
|
| Dimensions: | 181 mm x 107 mm (not including the mounting bracket)
|
|
SGRAM Display Mem. | 4 MB | 8 MB |
| Resolution | Colors | Hz (max.) | Colors | Hz (max.)
| | 1920 x 1200 | 256 | 73 | 256/32K | 73/73
| | 1920 x 1080 | 256 | 79 | 256/32K | 79/79
| | 1792 x 1120 | 256/32K | 80/80 | 256/32K | 80/80
| | 1600 x 1200 | 256/32K | 85/85 | 256/32K | 85/85
| | 1600 x 1000 | 256/32K | 101/101 | 256/32K | 101/101
| | 1536 x 960 | 256/32K | 110/110 | 256/32K | 110/110
| | 1280 x 1024 | 256/32K | 130/130 | 256/32K/16M | 130/130/76
| | 1152 x 864 | 256/32K/16M | 171 /171/86 | 256/32K/16M | 171/171/100
| | 1024 x 768 | 256/32K/16M | 200/200/108 | 256/32K/16M | 200/200/108
| | 800 x 600 | 256/32K/16M | 200/200/177 | 256/32K/16M | 200/200/177
| | 640 x 480 | 256/32K/16M | 200/200/200 | 256/32K/16M | 200/200/200
|
32K = 32,768 colors; 16M = 16.7 million colors;
The values given here are maximums; smaller graphics modes and virtual resolutions are easily
set up in Windows( 95 with the WINman Suite.
(Maximum values may not be achievable under all operating systems and conditions.)
|
|
Package includes:
|
| Accessories: | MPEG software decoder with MMX-Support, comprehensive documentation in English and German,
installation guide in English, French, Italian, Spanish, Dutch and German; software and drivers all on CD-ROM;
WINman Suite (collection of tools for setting the resolution, timing, Direct3D features, and video filters);
Adapter cable, S-video/hosiden to composite/cinch
|
| Drivers: | ELSA drivers for Windows95, Windows NT4.0, OS/2 Warp 4
|
| Warranty: | 36 months
|
| Support: | via hotline, faxline, CompuServe, and Internet
|
| Art.No.: | 00939 WINNER 2000/Office-4 PCI bus, 4 MB (upgradable to 8 MB), video in / video out
00969 WINNER 2000/Office-8 PCI bus, 8 MB, video in / video out
00157 SGRAM module, 4 MB SO-DIMM memory expansion
|
|
MPEG playback via software: decoder included
|
采用3Dlabs 64位的图形加速芯片Permedia 2
