 128位元的娛樂效能帶給您爆發性的3D繪圖感受 ELSA VICTORY Erazor 開先鋒的將所有必須配備集合在一塊遊戲加速 卡上。能夠滿足每個狂熱的電腦玩家，要求完美的使用者，以及難以 自拔的電腦遊戲狂。此外在Direct 3D介面下，有著令人尖叫的卓越 表現和高畫質畫面，同時加速Win 95的能力和2D的繪圖表現更是傑 出。而且只要使用卡上的Video輸入輸出端子，就能在家裡的電視上 感受到大型遊戲機的震撼，以及畫質優美的MPEG和AVI播放效果。 甚至可錄下一系列的畫面，也可用來上網際網路會議。 |  |
 高速支援Direct 3D 128位元繪圖引擎強力加速Windows 95和Windows NT TV/video 的輸出端子可在您的TV或VCR上重現S-Video和VHS畫質畫面 TV/video 的輸入端子可在視訊會議畫面和錄製影像上重現S-Video和VHS畫質畫面 多項的過濾器能重現高畫質的MPEG和AVI影像檔 強有力的浮點幾何單位平行陣列以及虛擬材質記憶體 載有VBE 2.0BIOS超快DOS (Flash-BIOS, 軟體可升級)
|
| Specifications: | |||||||||||||||||||||||||
| Bus system: | PCI (AGP in preparation) | ||||||||||||||||||||||||
| Graphics controller: | RIVA128 by SGS Thomson | ||||||||||||||||||||||||
| Display memory: | 4 MB SGRAM, 1.6 GB/second bandwidth | ||||||||||||||||||||||||
| Texture memory: | Graphics memory and system RAM, on-board texture cache | ||||||||||||||||||||||||
| Pixel clock: | up to 230 MHz | ||||||||||||||||||||||||
| Graphics standards: | Microsoft Direct3D, DirectDraw and OpenGL (mini-client driver for Windows NT) | ||||||||||||||||||||||||
| 3D features: | Triangle setup engine, 32-bit bilinear filtering, multipass rendering, alpha blending, texture color keying, fogging, Gouraud shading, LOD MIP mapping, Z-buffer, and much more | ||||||||||||||||||||||||
| Video inputs: | PAL/NTSC/SECAM, hosiden (S-Video) and two cinch (composite) plugs, selectable, full PAL/NTSC resolution, Video-for-Windows capture driver, | ||||||||||||||||||||||||
| alternatively selectable: | video input port using CCIR-656 standard (for optional expansions) | ||||||||||||||||||||||||
| Video outputs: | PAL/NTSC, hosiden (S-Video) and cinch (Composite) plugs, as alternative to the monitor | ||||||||||||||||||||||||
| Other standards: | VESA BIOS 2.0, DPMS, DDC2B, Plug&Play | ||||||||||||||||||||||||
| Dimensions: | 146 mm x 107 mm (not including the mounting bracket) | ||||||||||||||||||||||||
64K= 65.536 colors; 16M = 16.7 million colors; The values given here are maximums (Maximum values may not be achievable under all operating systems and conditions.) | |||||||||||||||||||||||||
| Package includes: | |||||||||||||||||||||||||
| Accessories: | MPEG software decoder, comprehensive documentation in English, German and French Installation guide in English, German, French, Italian, Dutch, and Spanish Software and drivers all on CD-ROM | ||||||||||||||||||||||||
| Driver: | Windows95, Windows NT4.0, Windows NT3.51 | ||||||||||||||||||||||||
| Warranty: | 36 months | ||||||||||||||||||||||||
| Support: | via hotline, faxline, CompuServe, and Internet | ||||||||||||||||||||||||
| Art.No.: | 00593 ELSA VICTORY Erazor-4, 4 MB, PCI | ||||||||||||||||||||||||
| MPEG playback via software decoder; decoder included | |||||||||||||||||||||||||
Subject to change without notice paper bleached without chlorine |  |
