滿足 3D TrueColor 高解析度CAD視覺化處理需求的高階圖形加速卡
ELSA GLoria-XL為PC-based圖形處理性能再塑里程碑，對於那些複雜
極專業的3D視覺化處理軟體而言，ELSA GLoria-XL為新生代的工作站
再創威力，是您實現Virtual Reality的最佳工具， 其快速又龐大的材
質貼圖記憶體更是您在3D TrueColor CAD構圖時的最佳工具。
在TrueColor 3D模式下，最高解析度可達1920 x 1080像素(pixels)
龐大的local buffer可滿足特別需要材質處理的應用軟體
支援Windows NT(r)環境下多卡多螢幕顯示
支援高性能圖形介面規格 OpenGL(r), HEIDI 和 Direct3D

Equipment:
Graphics processorGLINT MX (3Dlabs)
3D-coprocessor GLINT Delta (3Dlabs)
Boot VGATrio64V2/DX with 1 MB DRAM (S3)
RAMDAC / pixel clockRGB 640 (IBM) / 250 MHz
Memory16 MB VRAM, 24 MB DRAM (upgradable to 40 MB DRAM)
BIOSVBE 2.0 support
Bus systemPCI
Performance:
Line frequency31 - 300 kHz
Graphics standardsOpenGL(r), HEIDI, Direct3D, DirectDraw
3D featureshardware texture MIP-mapping, antialiasing, fogging, overlay, stencil, alpha planes
Multi-screen operationfor Windows NT(r) 4.0/3.51
StandardsVESA DPMS, DDC2B
Connectorsmonitor connector: D-shell 15-pin
Dimensions341 x 107 mm (including retainer, not including mounting bracket)
3D Resolutions:
Z-buffering /
Double buffering		 Refresh rate with
TrueColor / HiColor		Available texture memory
24 MB DRAM40 MB DRAM
1920 x 1200*76 Hz (HiColor)7 MB23 MB
1920 x 108085 Hz8 MB24 MB
1600 x 128078 Hz8 MB24 MB
1600 x 120084 Hz8.5 MB24.5 MB
1600 x 1000*104 Hz10 MB26 MB
1280 x 1024131 Hz11 MB27 MB
1152 x 864184 Hz12 MB28 MB
1024 x 768231 Hz13 MB29 MB
These values are maximums, and may not be achievable under all operating systems and conditions.
Other graphics modes are easily set up in Windows(r). *): special resolution for 16:10 wide-format
monitors (e.g. ELSA ECOMO 24H96)
HiColor = 32,768 colors / TrueColor = 16.7 million colors.
Drivers/Software:
Operating systemsWindows NT(r) 4.0/3.51, Windows(r)95
CAD ELSA POWERdraft display list driver for AutoCAD R13; ELSA POWERview 3D for 3D visualization under AutoCAD R13/R14, Autodesk Mechanical Desktop, and as stand-alone application
OtherELSA high-performance drivers for OpenGL(r), HEIDI, Direct3D
Windows utilitiesELSA WINman Suite (tools collection for setting resolution, timings, 3D features)
Supported applications:
SelectionSoftimage 3D, Pro/ENGINEER, Pro/MECHANICA, AutoCAD, Autodesk Mechanical Desktop, LightWave 3D, 3D Studio MAX/VIZ, MicroStation95, MicroStation Modeler, I-DEAS, Solid Edge, Lightscape, WorldToolKit, dVISE, CA Unicenter TNG, SolidWorks, EDS/Unigraphics, Superscape, VISPLAN, Real 3D 3.5, GLView, AVS/Express, Open Inventor, LogoCAD, HICAD, ALLPLAN, ANSYS, AnySIM, MICROCADAM Helix, Extreme 3D, CADdy ++, ANVIL5000 and many more.
Package contents:
Manualcomprehensive documentation in English and German
Installation GuideEnglish, German, French, Italian, Spanish, and Dutch
Drivers/softwareCD-ROM ELSA WINNERware
Demo softwareCD-ROM CADware
Service:
Warranty36 months
Supportvia hotline, faxline, BBS, CompuServe, and Internet
Article number:
ELSA GLoria-XL 0691
16 MB DRAM upgrade0879
Subject to change without notice
paper bleached without chlorine
