提供專業動畫的最佳表現，與3D Ture Color高解析度CAD
視覺化處理需求的高階AGP圖形加速卡
ELSA GLoria-XXL是ELSA在高階圖形加速卡，GLoria系列中推出的
AGP卡。所有專業人士所要求的精確細緻的動畫，呈現完美的視覺
效果，快速精準的3D CAD模型及完全感受虛擬實境的快感，都能
在ELSA GLoria-XXL得到了完全的滿足。搭配了快速的AGP匯流排
及由3Dlabs最新出品的GLINT MX3D圖形處理器 與Gamma幾何運算
器，ELSA GLoria-XXL的絕佳表現將為PC-工作站立下全新的標準
與典範。除此之外，更值得一提的是ELSA GLoria-XXL並支援16:10
寬廣角螢幕，尤其是搭配ELSA ECOMO 24H96，所呈現的視覺效果
將更上層樓。
在True Color 3D模式下，最高解析度可達1920*1080像素(pixels)
龐大的local buffer可滿足特別需要材質處理的應用軟體
AGP匯流排
採用3Dlabs所出品的GLINT MX 3D圖形處理器與Gamma幾何運算器
支援高性能的3D標準圖形介面規格OpenGL(r)與Direct 3D
3D立體液晶眼鏡接頭

Equipment
Graphics processorGLINT MX (3Dlabs)
3D-coprocessorGLINT Gamma (3Dlabs)
Boot VGAPermedia2 with 2 MB SGRAM (3Dlabs)
RAMDAC / pixel clockRGB640 (IBM) / 250 MHz
Memory16 MB VRAM, 24 MB DRAM (upgradable to 40 MB DRAM)
BIOSVBE 2.0 support (640 x 480, 640 x 400)
Bus systemAGP 66 MHz
Performance
Line frequency31 - 300 kHz
Graphics standardsOpenGL(r), (under Windows NT(r)), Direct3D, DirectDraw
3D hardware featurestexture MIP-mapping, lighting, geometry, antialiasing, fogging, overlay, and many more
StandardsVESA DPMS, DDC2B
Connectorsmonitor connector; D-shell 15-pin: Shutter glasses; VESA mini DIN connector
Dimensions341 x 107 mm (including retainer, not including mounting bracket)
3D Resolutions
Z-buffering /
Double buffering		Refresh rate with
TrueColor / HiColor		 Available texture memory
24 MB DRAM40 MB DRAM
1920 x 1200*76 Hz (HiColor)7 MB23 MB
1920 x 108085 Hz8 MB24 MB
1600 x 128078 Hz8 MB24 MB
1600 x 120084 Hz8.5 MB24.5 MB
1600 x 1000*104 Hz10 MB26 MB
1280 x 1024131 Hz11 MB27 MB
1152 x 864184 Hz12 MB28 MB
1024 x 768231 Hz3 MB29 MB
These values are maximums, and may not be achievable under all operating systems and conditions.
Other graphics modes are easily set up in Windows(r). * special resolution for 16:10 wide-format
monitors (e.g. ELSA ECOMO 24H96)
HiColor = 32,768 colors / TrueColor = 16.7 million colors.
Drivers/Software
Operating systemsWindows NT(r) 4.0/3.51, Windows(r)95
CAD ELSA POWERdraft display list driver for AutoCAD R14 ELSAview 3D for 3D visualization under AutoCAD R13/R14, Autodesk Mechanical Desktop, and as stand-alone application
Other ELSA high-performance drivers for OpenGL and Direct3D
Windows utilitiesELSA WINman Suite (GLoria Settings, ELSAinfo, monitor control)
Supported applications
Selection Softimage 3D, Pro/ENGINEER, Pro/MECHANICA, AutoCAD for Windows(r), Autodesk Mechanical Desktop, LightWave 3D, 3D Studio MAX/VIZ, MicroStation95, MicroStation Modeler, I-DEAS, Solid Edge, Lightscape, WorldToolKit, dVISE, CA Unicenter TNG, SolidWorks, EDS/Unigraphics, Superscape, VISPLAN, Real 3D 3.5, GLView, AVS/Express, Open Inventor, LogoCAD, HICAD, ALLPLAN, ANSYS, AnySIM, MICROCADAM Helix, Extreme 3D, CADdy ++, ANVIL5000 and many more.
Package contents
Manual comprehensive documentation in English and German
Installation Guide English, German, French, Italian, Spanish, and Dutch
Drivers/softwareCD-ROM ELSA WINNERware
Service
Warranty6 years
Supportvia hotline, faxline, ELSA LocalWeb, CompuServe, and Internet
Article number
ELSA GLoria-XXL0931
16 MB DRAM upgrade0879
Subject to change without notice
paper bleached without chlorine
